The OneScreen TL7 is a powerful, all-in-one interactive touchscreen solution designed to enhance collaboration, productivity, and engagement in classrooms and corporate environments. With advanced touch technology, built-in software, and seamless connectivity, the TL7 transforms how teams and students interact.
Key Features:
- Screen Size: 65” LED, 4K UHD (3840 x 2160 resolution)
- Operating System: Android 11 & Windows 11 (via OPS)
- Touch Points: Supports up to 40 simultaneous touch points
- Touch Technology: Zero Bonding IR (Gen 2), <7 ms response time
- Processor: Quad-core ARM Cortex A55 (up to 1.8 GHz)
- RAM/Storage: 8 GB RAM / 64 GB internal storage
- Brightness: 400 cd/m² | Aspect Ratio: 16:9 | Refresh Rate: 60Hz
- Glass: Level 7 MoHS anti-glare & anti-fingerprint surface
- Viewing Angle: 178°
- Audio: 2x 16W speakers with stereo output
Software & Tools:
- OneScreen Write – Interactive whiteboarding with cloud drive support
- OneScreen Share – Two-way screen sharing for up to 9 devices
- OneScreen Central – Remote device & app management
- OneScreen LearningHub & Class – Streamlined conferencing and classroom engagement tools
- Built-in Tools – Stopwatch, screen recorder, screen capture, multitasking, etc.
Ports & Connectivity:
- Side Ports: 2x HDMI-In, 1x VGA-In, 1x Audio-In, HDMI-Out, USB Touch, Audio-Out, SPDIF-Out, RS-232, 2x RJ-45, 2x USB 3.0, USB 2.0, OPS slot
- Front Ports: HDMI-In, USB Touch, 2x USB 3.0, 1x USB Type-C (65W PD)
- Connectivity: Wi-Fi 6, Bluetooth 5.2, Gigabit Ethernet
Included Accessories:
- 1x HDMI cable
- 1x Power cable
- 1x USB Touch cable
- 1x Type-C cable
- 2x Stylus pens (anti-bacterial)
- 1x Remote control
- Wall mount (VESA 600 x 400 mm)
Power:
- Voltage: 100 - 240V AC (50/60 Hz)
- Typical Consumption: 200W
- Max Consumption: 360W
Dimensions & Weight:
- Product: 58.60” x 35.30” x 3.43” | 77.05 lbs
Support & Warranty:
- Warranty: 3 years standard (extended warranty options available)
- Certifications: CE, FCC, UL, RoHS, WEEE, CB, Energy Star
- 24/6 Guru Support – Free live help via chat, email, phone, or video
